| Model | Volt (V) |
Capacity (Ah ) |
Dimension (mm) | Approx. Weight (Kg) |
Terminal Type |
|||
|---|---|---|---|---|---|---|---|---|
| L | W | H | T.H. | |||||
| EV12-12 | 12 | 12 | 151 | 100 | 99 | 99 | 4.2 | M5 |
| EV20-12 | 12 | 20 | 180 | 76 | 170 | 170 | 6.5 | M5 |
| EV22-12 | 12 | 22 | 180 | 76 | 170 | 170 | 7 | M5 |
| EV24-12 | 12 | 24 | 185 | 105 | 130 | 130 | 7.2 | M5 |
| EV28-12 | 12 | 28 | 175 | 166 | 125 | 125 | 9.8 | M5 |
| EV14-16 | 16 | 14 | 201 | 112 | 102 | 102 | 7 | M5 |
| EV20-16 | 16 | 20 | 250 | 100 | 130 | 130 | 9.8 | M5 |
| EV180-6 | 6 | 180 | 260 | 180 | 270 | 275 | 33 | M8 |
| EV200-6 | 6 | 200 | 260 | 180 | 270 | 275 | 35 | M8 |
| EV225-6 | 6 | 225 | 260 | 180 | 270 | 275 | 36 | M8 |
| EV150-8 | 8 | 150 | 260 | 180 | 280 | 285 | 35.5 | M8 |
| EV32-12 | 12 | 32 | 266 | 76 | 170 | 170 | 10 | M5 |
| EV35-12 | 12 | 32 | 223 | 93 | 175 | 175 | 10 | M5 |
| EV40-12 | 12 | 40 | 223 | 120 | 175 | 175 | 12.3 | M5 |
| EV42-12 | 12 | 42 | 197 | 165 | 176 | 176 | 14.5 | M5 |
| EV45-12 | 12 | 45 | 223 | 120 | 175 | 175 | 13 | M5 |
| EV50-12 | 12 | 50 | 223 | 135 | 177 | 177 | 15 | M5 |
| EV55-12 | 12 | 58 | 230 | 150 | 180 | 180 | 16.5 | M6 |
| EV60-12 | 12 | 60 | 260 | 170 | 160 | 162 | 19.5 | M6 |
| EV70-12 | 12 | 70 | 260 | 170 | 210 | 210 | 23 | M6 |
| EV80-12 | 12 | 80 | 260 | 170 | 210 | 210 | 26.5 | M6 |
| EV100-12 | 12 | 100 | 330 | 171 | 210 | 210 | 34 | M8 |
| EV120-12 | 12 | 120 | 407 | 170 | 240 | 240 | 40 | M8 |
| EV150-12 | 12 | 150 | 483 | 170 | 240 | 240 | 49 | M8 |
| EV200-12 | 12 | 200 | 522 | 240 | 220 | 228 | 66 | M8 |
| EVT105 | 6 | 225 | 262 | 181 | 280 | 289 | 22/31 | DT |
| EVT875 | 8 | 180 | 260 | 180 | 283 | 290 | 23/33 | DT |
